Polini engine housing 4-flap diaphragm & starter pedal | Peugeot 103, 104, 105, GL 10

Airsal 40 mm cylinder kit | Peugeot 103

Manufacturer: Airsal · Camouflaged: No · Area of application: Tuning · Material: Aluminum · Surface: sandblasted · Nominal diameter: 40 mm · Ø piston pin (B): 12 mm · Number of fixing points: 4 pcs

Airsal 46 mm cylinder kit | Peugeot 103

Manufacturer: Airsal · Camouflaged: No · Area of application: Tuning · Material: Aluminum · Surface: sandblasted · Displacement: 72 ccm · Nominal diameter: 46 mm · Ø piston pin (B): 12 mm · Number of fixing points: 4 pcs

Malossi Rennvariomat Multivar | Peugeot 103 SPX, RCX

Manufacturer: Malossi · Gearbox type: Vario · Number of weights: 6 pcs · Weight Standard weights: 3 g · Ø Weights: 16 mm · Length Weights: 12.8 mm

swiing® ingenious brake shoes Ø 90 x 17 Racing slotted | Peugeot 103

Manufacturer: swiing® ingenious parts · Ø drum: 90 mm · Width: 17 mm · Number of springs: 1 pcs · Springs included: Yes · Slotted: Yes · Area of application: Racing

Simonini exhaust snail | Peugeot 103 SP

Manufacturer: Simonini · Material: Steel · Surface: varnished · Exhaust type: Snail · Mounting type: Welded lug · Number of fixing points: 2 pcs · Flame tube attachment: Plug connection clamped

Athena 40 mm cylinder kit aluminum | Peugeot 103 VOGUE T, L

Nominal diameter: 40 mm · Manufacturer: Athena · Material: Aluminum · Surface: sandblasted · Ø piston pin (B): 12 mm · Outlet type: Union nut · Outlet type: slanted · Number of fixing points: 4 pcs · Camouflaged: No · Area of application: Tuning

Set of clutch shoes lightened | Peugeot 103 SPX, RCX

Number of jaws: 3 pcs · Number of springs: 3 pcs · Area of application: Tuning

Airsal cylinder head 40 mm | Peugeot 103

Manufacturer: Airsal · Material: Aluminum · Surface: sandblasted · Ø cylinder: 40 mm · Number of fixing points: 4 pcs · Hole pattern [mm]: 49.5 x 45 · Candle thread: short · Decompressor: Yes · Width: 105 mm · Height: 110 mm · Area of application: Standard

Polini racing exhaust | Peugeot 103, 103 SPX50, 104, 105, GL 10

Manufacturer: Polini · Material: Steel · Exhaust type: Cone / double cone · Mounting type: Flange · Number of fixing points: 4 pcs · Flame tube attachment: Stud bolts & nuts

Polini engine housing 4-flap diaphragm | Peugeot 103, 104, 105, GL 10

Manufacturer: Polini · Material: Cast aluminum · Crankshaft stroke: 39 mm · Hole pattern [mm]: 45 x 50

Polini 46 mm cylinder kit cast iron | Peugeot 103, 104, 105, GL 10

Nominal diameter: 46 mm · Manufacturer: Polini · Material: Gray cast iron · Displacement: 65 ccm · Crankshaft stroke: 39 mm · Ø cylinder neck: 49.9 mm · Ø outlet inside: 23.5 mm · Ø piston pin (B): 12 mm · Hole spacing outlet: 50 mm · Number of fixing points: 4 pcs · Hole pattern [mm]: 46 x 50 · Area of application: Tuning

Polini gasket set 4-flap diaphragm housing | Peugeot 103, 104, 105, GL

Manufacturer: Polini · Material: Sealing paper · Number of components: 4 pcs · Hole pattern [mm]: 48 x 42

Polini crankshaft (electronic ignition) | Peugeot 103, 104, 105, GL 10

Manufacturer: Polini · Material: Steel · Cheek type: Full cheeks · Crankshaft stroke: 39 mm · Connecting rod length center-center: 76 mm · Total length of crankpin on clutch side: 100 mm · Total length crankpin ignition side: 71 mm · Ø crank webs: 69 mm · Ø piston pin (B): 12 mm · Ø Connecting rod eye: 16 mm · Ø Bearing seat (clutch side): 20 mm · Ø Bearing seat (ignition side): 17 mm · Thread type: MF10x1 (fine pitch thread) · Thread type: MF11x1 (fine pitch thread) · Thread length: 10 mm · Thread length: 15 mm · Dimension needle bearing: 12 / 15 x 17.2 mm (axe 12) · Wide crank webs: 35.1 mm · Length 1st paragraph: 23 mm · Length 2nd paragraph: 8 mm · Length 3rd paragraph: 59 mm · Ø 1st step (on the coupling side): 20 mm · Ø 2nd shoulder (on the clutch side): 15.9 mm · Ø 3rd step (on the clutch side): 10.9 mm · Length of shoulder (ignition side): 12 mm · Weight: 954 g · Area of application: Racing · Area of application: Tuning

Polini 46 mm cylinder kit aluminum | Peugeot 103, SPX50, 104, 105, GL 10

Nominal diameter: 46 mm · Manufacturer: Polini · Material: Aluminum · Displacement: 65 ccm · Ø cylinder neck: 50 mm · Ø Outlet outside: 25 mm · Ø piston pin (B): 7 mm · Outlet type: slanted · Hole spacing outlet: 50 mm · Thread outlet: M7x1 (standard thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 45.4 x 50.5 · Decompressor: Yes · Camouflaged: No
