Spare parts catalog | Puch X30 NS / NL (CH)

Karcoma fuel tap M12x1 vertical (with union nut) plastic connection

Manufacturer: Karcoma · Possible lever positions: open / closed / reserve · Thread type: MF12x1 (fine pitch thread) · Material lever: Metal · Filter type: Plastic net · Installation direction: vertical / vertical · Outlet direction: any · Spare tube shape: straight · Ø fuel hose connection: 6 mm · Reserve level: 50 mm · Mounting type: Union nut

swiing® revival cable guide mudguard black | Puch

Manufacturer: swiing® revival parts · Material: Plastic · Total length: 74 mm · Color: black · Height: 12.5 mm · Hole spacing: 63 mm · Mounting type: Plug connection · Number of fixing points: 2 pcs

swiing® revival air filter screen Ø 52 mm original

Manufacturer: swiing® revival parts · Camouflaged: No · Material: Steel · Surface: galvanized (blue) · Ø outside: 52 mm · Color: silver · Height: 10 mm · Area of application: Standard

Repair instructions | Puch X30 NS/NL

Material: Paper · DIN format: A4 · Number of pages: 29 pcs · Language: German

Manual indoor cable set

Manufacturer: Made in Germany · Material: Steel · Ø Stranded wire: 1.2 mm · Ø Stranded wire: 1.25 mm · Ø Stranded wire: 1.5 mm · Ø Stranded wire: 1.8 mm · Quantity: 4 pcs · Total length: 2200 mm · Nipple shape: Barrel (transverse) · Nipple shape: Cylinder · Nipple shape: Pears

Manual cable set black

Material: Steel · Ø Stranded wire: 1.2 mm · Ø Stranded wire: 1.25 mm · Ø Stranded wire: 1.5 mm · Ø Stranded wire: 1.8 mm · Quantity: 4 pcs · Total length: 2200 mm · Color: black · Outer shell length: 6000 mm · Nipple shape: Barrel (transverse) · Nipple shape: Cylinder · Nipple shape: Pears

Operating instructions | Puch X30 Sport NS/NL

Material: Paper · DIN format: A5 · Number of pages: 48 pcs · Language: German

swiing® revival "must have" ignition setting instructions

Manufacturer: swiing® revival parts · Material: Paper · DIN format: A5 · Number of pages: 17 pcs · Language: German
