Malossi intake manifold 15 mm Dell'Orto SHA | Puch / Minarelli V1

Dell'Orto 16/16 SHA carburetor hand choke

Manufacturer: Dell'Orto · Component group Carburetor: Carburetor complete · Material: Aluminum · Area of application: Tuning · Color: black · Carburetor type: SHA · Nominal diameter: 16 mm · Width: 72 mm · Ø fuel hose connection: 5.1 mm · Ø fuel hose connection: 6 mm · Height: 111 mm · Mounting type: Plug connection clamped · Ø without reducing sleeve: 21 mm · Nozzle size: 82 · Ø Inside entrance: 16 mm · Ø Internal connection: 19 mm · Total length: 82 mm · Ø Output inside: 16 mm · Ø Air filter connection: 56 mm · Ø Air filter connection: 58.5 mm · Mixed oil connection: No · Vacuum connection: No · Choke control: Hand choke · Nozzle thread: M5x0.8 (standard thread) · Camouflaged: No

Dell'Orto 15/15 SHA carburetor hand choke (with air filter)

Manufacturer: Dell'Orto · Camouflaged: No · Area of application: Racing · Area of application: Tuning · Component group Carburetor: Carburetor complete · Material: Aluminum · Carburetor type: SHA · Nominal diameter: 15 mm · Total length: 82 mm · Width: 70 mm · Ø fuel hose connection: 5.3 mm · Ø fuel hose connection: 6 mm · Ø Internal connection: 18 mm · Height: 100 mm · Ø without reducing sleeve: 21 mm · Ø Inside entrance: 15 mm · Ø Output inside: 15 mm · Mounting type: Plug connection clamped · Color: black · Ø Air filter connection: 59 mm · Mixed oil connection: No · Vacuum connection: No · Choke control: Hand choke · Nozzle thread: M5x0.8 (standard thread) · Nozzle size: 68

Dell'Orto 15/15 SHA carburetor cable choke

Manufacturer: Dell'Orto · Area of application: Tuning · Component group Carburetor: Carburetor complete · Width: 69 mm · Choke control: Cable choke · Carburetor type: SHA · Nominal diameter: 15 mm · Height: 82 mm · Total length: 58 mm · Nozzle thread: M5x0.8 (standard thread) · Ø fuel hose connection: 6 mm · Ø without reducing sleeve: 21 mm · Nozzle size: 68 · Ø Inside entrance: 15 mm · Ø Output inside: 15 mm · Mounting type: Plug connection clamped · Ø Air filter connection: 59 mm · Ø Internal connection: 19 mm

Polini 47 mm cylinder kit | Minarelli V1

Nominal diameter: 47 mm · Manufacturer: Polini · Camouflaged: No · Surface: varnished · Displacement: 75 ccm · Material: Gray cast iron · Hole spacing inlet: 38.5 mm · Ø outlet inside: 20.5 mm · Ø Inlet inside: 18.3 mm · Area of application: Tuning · Number of fixing points: 4 pcs · Ø piston pin (B): 12 mm · Hole spacing outlet: 38 mm · Thread inlet: M5x0.8 (standard thread) · Hole pattern [mm]: 46 x 46 · Outlet type: straight · Thread outlet: M6x1 (standard thread) · Decompressor: none

Dell'Orto 16/16 SHA carburetor hand choke

Manufacturer: Dell'Orto · Component group Carburetor: Carburetor complete · Material: Aluminum · Area of application: Tuning · Color: black · Carburetor type: SHA · Nominal diameter: 16 mm · Width: 72 mm · Ø fuel hose connection: 5.1 mm · Ø fuel hose connection: 6 mm · Height: 111 mm · Mounting type: Plug connection clamped · Ø without reducing sleeve: 21 mm · Nozzle size: 82 · Ø Inside entrance: 16 mm · Ø Internal connection: 19 mm · Total length: 82 mm · Ø Output inside: 16 mm · Ø Air filter connection: 56 mm · Ø Air filter connection: 58.5 mm · Mixed oil connection: No · Vacuum connection: No · Choke control: Hand choke · Nozzle thread: M5x0.8 (standard thread) · Camouflaged: No

Motorex Automatic Motor Oil (ATF) 450 ml

Manufacturer: Motorex · Contents [ml]: 450 ml · Gearbox type: Automatic machine · Temperature resistance (min.): -45 - 200 °C · Area of application: Gearbox lubrication with clutch · Pony OEM number: A2080 · Sachs OEM no.: 0263 014 002

Gas cable Ø 1.2 mm x 165 cm (nipple ball) Dell'Orto

Ø Stranded wire: 1.2 mm · Nipple shape: Ball · Ø nipple: 3.5 mm · Manufacturer: Made in Germany · Surface: galvanized (blue) · Material: Steel · Cable length: 1650 mm · Number of components: 1 pcs · Area of application: Standard

Outlet gasket 18 - 22 mm metal ring

Material: Sealing carton · Material: Sheet metal (steel) · Ø inside: 22 mm · Place of use: Outlet · Thickness: 2 mm · Hole spacing: 38 - 42.5 mm · Number of fixing points: 2 pcs · Ø mounting hole: 6.7 mm

Dell'Orto 15/15 SHA carburetor hand choke (with air filter)

Manufacturer: Dell'Orto · Camouflaged: No · Area of application: Racing · Area of application: Tuning · Component group Carburetor: Carburetor complete · Material: Aluminum · Carburetor type: SHA · Nominal diameter: 15 mm · Total length: 82 mm · Width: 70 mm · Ø fuel hose connection: 5.3 mm · Ø fuel hose connection: 6 mm · Ø Internal connection: 18 mm · Height: 100 mm · Ø without reducing sleeve: 21 mm · Ø Inside entrance: 15 mm · Ø Output inside: 15 mm · Mounting type: Plug connection clamped · Color: black · Ø Air filter connection: 59 mm · Mixed oil connection: No · Vacuum connection: No · Choke control: Hand choke · Nozzle thread: M5x0.8 (standard thread) · Nozzle size: 68

Polini gasket set cylinder Minarelli V1 engine

Manufacturer: Polini · Number of components: 4 pcs · Ø cylinder: 47 mm · Area of application: Tuning

Polini 47 mm cylinder kit | Minarelli V1

Nominal diameter: 47 mm · Manufacturer: Polini · Camouflaged: No · Surface: varnished · Displacement: 75 ccm · Material: Gray cast iron · Hole spacing inlet: 38.5 mm · Ø outlet inside: 20.5 mm · Ø Inlet inside: 18.3 mm · Area of application: Tuning · Number of fixing points: 4 pcs · Ø piston pin (B): 12 mm · Hole spacing outlet: 38 mm · Thread inlet: M5x0.8 (standard thread) · Hole pattern [mm]: 46 x 46 · Outlet type: straight · Thread outlet: M6x1 (standard thread) · Decompressor: none

Malossi gasket inlet Ø 22 mm | Minarelli V1

Manufacturer: Malossi · Ø outlet inside: 22 mm · Thickness: 0.55 mm · Place of use: Admission · Hole spacing inlet: 36 - 45 mm

GPO gasket exhaust metal ring 18 - 22 mm | Minarelli / Morini

Manufacturer: GPO · Thickness: 2 mm · Ø inside: 22.15 mm · Number of fixing points: 2 pcs · Place of use: Outlet · Hole spacing: 38 - 43 mm
