Meteor piston ring 41 x 1.5 mm (FS) hard chrome-plated for aluminum cylinder

Manufacturer: Meteor · Surface: hard chrome plated · Diameter: 41 mm · Nominal diameter: 41 mm · Thick piston ring: 1.7 mm · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Height: 1.5 mm

GPO gasket set slot version | Sachs 50/3 3-speed engine

Manufacturer: GPO · Number of components: 8 pcs · Ø outlet inside: 28 mm · Hole spacing inlet: 31 mm · Area of application: Standard · Hole pattern [mm]: 51 x 40

swiing® revival screw set fan wheel EVO & HPI ignition Inox

Manufacturer: swiing® revival parts · Material: Chrome steel (known as Nirosta®) · Thread type: M6x1 (standard thread) · Drive: Slot · Number of components: 6 pcs

Gasket set diaphragm version | Sachs 3-speed 50/3 engine

Number of components: 9 pcs · Ø outlet inside: 28 mm · Hole spacing inlet: 67 mm · Area of application: Standard · Hole pattern [mm]: 51 x 40

Inlet seal oil paper | Sachs

Material: Oiled paper · Place of use: Admission · Thickness: 0.45 mm · Ø outlet inside: 14.5 mm · Hole spacing inlet: 32 mm

Oil seal FPM 15/30/5.5 AS crankshaft & main shaft | Sachs 503, 504, 505, 535 (A4215 / A5602)

Place of use: Crankshaft · Temperature resistance (min.): -30 - 200 °C · Simmering type: AS - With rubberized outer casing / one sealing lip / one dust lip. · Ø inside: 15 mm · Ø outside: 30 mm · Width: 5.5 mm · Manufacturer: Sachs · Material: FPM - Fluororubber · Surface: rubberized · Pony OEM number: A5602 · Sachs OEM no.: 0230 111 100

Shaft seal NBR 16/24/4 A Pedal start mechanism | Sachs 50/2, 50/3, 50/4

Temperature resistance (min.): -30 - 100 °C · Simmering type: A - With rubberized outer part / one sealing lip. · Ø inside: 16 mm · Ø outside: 24 mm · Width: 4 mm · Manufacturer: Sachs · Material: NBR · Surface: rubberized

swiing® ingenious assembly aid pinion shaft | Sachs 50/2, 503

Manufacturer: swiing® ingenious parts · Material: Aluminum · Area of application: Special tool · Surface: anodized · Total length: 20 mm · Ø inside: 12 mm · Ø outside: 15.5 mm

swiing® ingenious fan wheel chrome (EVO, HPI, Bosch, Ducati) | Sachs 50/2, 50/3

Manufacturer: swiing® ingenious parts · Material: Aluminum · Surface: chrome-plated · Color: Chrome · Ø outside: 110 mm · Ø inside: 39 mm · Ø mounting hole: 6 mm · Ø bolt circle: 48 mm · Number of fixing points: 6 pcs · Height: 25 mm · Weight: 116 g · Alternative version of the Pony OEM number: A1026 · Alternative version of the Sachs OEM number: 0211 070 105

swiing® ingenious fan wheel red (EVO, HPI, Bosch, Ducati) | Sachs 50/2, 50/3

Manufacturer: swiing® ingenious parts · Material: Aluminum · Surface: anodized · Color: red · Ø outside: 110 mm · Ø inside: 39 mm · Ø mounting hole: 6 mm · Ø bolt circle: 48 mm · Number of fixing points: 6 pcs · Height: 25 mm · Weight: 116 g · Alternative version of the Pony OEM number: A1026 · Alternative version of the Sachs OEM number: 0211 070 105

GPO piston 40.92 mm | Sachs 50/2, 50/3, 50/4

Manufacturer: GPO · Nominal diameter: 41 mm · Ø outside piston (A): 40.92 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 2.5 mm · Total piston height (E): 52 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.5 mm · Piston weight: 91 g

swiing® revival plain bearing driver | Sachs 502 AML, 503 AAL (A1179)

Ø inside: 16 mm · Nominal diameter inside: 16 mm · Ø outside: 18 mm · Total height: 18.2 mm · Manufacturer: swiing® revival parts · Material: special bearing bronze · Area of application: Original · Area of application: Performance · Area of application: Racing · Area of application: Tuning · Pony OEM number: A1179 · Sachs OEM no.: 0232 141 001

swiing® revival plain bearing clutch basket | Sachs 502 AML, 503 AAL (A1178)

Ø inside: 16 mm · Nominal diameter inside: 16 mm · Ø outside: 18 mm · Ø Bundle: 22 mm · Total height: 14.75 mm · Manufacturer: swiing® revival parts · Material: special bearing bronze · Area of application: Original · Area of application: Performance · Area of application: Racing · Area of application: Tuning · Pony OEM number: A1178 · Sachs OEM no.: 0232 141 000

Meteor piston ring 41 x 1.5 mm (FS) black

Manufacturer: Meteor · Diameter: 41 mm · Nominal diameter: 41 mm · Thick piston ring: 1.7 mm · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Height: 1.5 mm

swiing® ingenious piston 38 mm | Sachs 50/2

Manufacturer: swiing® ingenious parts · Nominal diameter: 38 mm · Ø outside piston (A): 37.96 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3.4 mm · Total piston height (E): 54 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 1.5 mm · Piston weight: 81 g

swiing® ingenious piston 41 mm | Sachs 50/2

Manufacturer: swiing® ingenious parts · Nominal diameter: 41 mm · Ø outside piston (A): 40.96 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3.4 mm · Total piston height (E): 53 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 1.5 mm · Piston weight: 91 g

swiing® ingenious 41 mm cylinder head tuning | Sachs 50/2, 50/3, 50/4

Manufacturer: swiing® ingenious parts · Material: Aluminum · Surface: sandblasted · Ø cylinder: 41 mm · Ø outside: 98 mm · Number of fixing points: 4 pcs · Height: 50 mm · Ø screw holder: 19 mm · Total length: 127 mm · Hole pattern [mm]: 37 x 37 · Width: 95 mm · Candle thread: long · Decompressor: M10x1.5 · Area of application: Standard

swiing® ingenious 38 mm cylinder head tuning | Sachs 50/2, 50/3, 50/4

Manufacturer: swiing® ingenious parts · Material: Aluminum · Surface: sandblasted · Ø cylinder: 38 mm · Number of fixing points: 4 pcs · Hole pattern [mm]: 37 x 37 · Decompressor: M10x1.5

swiing® ingenious 41 mm gasket set cylinder | Sachs 50/2 (CH version)

Manufacturer: swiing® ingenious parts · Number of components: 3 pcs · Ø cylinder: 41 mm · Hole spacing inlet: 31 mm · Hole pattern [mm]: 60 x 40 mm / 37 x 37 mm · Area of application: Tuning

NSK sleeve freewheel clutch basket | Sachs 503 AB, ABL automatic

Manufacturer: NSK · Material: Sheet metal (steel) · Material: Steel · Stock number: HF1416 · Ø inside: 14 mm · Ø outside: 20 mm · Height: 15.9 mm

Inlet seal Ø 12 / 0.3 mm | Sachs 502, 50/2

Place of use: Admission · Thickness: 3 mm · Ø outlet inside: 12 mm · Hole spacing inlet: 31 mm · Pony OEM number: A1839 · Sachs OEM no.: 0250 105 000

Outlet gasket Ø 27 mm | Sachs 503 ADV

Manufacturer: Made in Italy · Ø inside: 27 mm · Thickness: 2 mm · Ø mounting hole: 6 mm · Place of use: Outlet · Number of fixing points: 2 pcs · Hole spacing: 43 - 50 mm

Oil seal FPM 15/30/7 BS | Sachs 50/2, 503

Simmering type: BS - With sheet metal outer casing / one sealing lip / one dust lip. · Manufacturer: Sachs · Temperature resistance (min.): -30 - 200 °C · Material: FPM - Fluororubber · Width: 7 mm · Ø inside: 15 mm · Ø outside: 30 mm · Pony OEM number: A1830 · Sachs OEM no.: 0250 090 000

42 mm cylinder kit | Sachs 5V

Material: Aluminum · Area of application: Tuning · Surface: sandblasted · Crankshaft stroke: 42 mm · Nominal diameter: 42 mm · Number of fixing points: 4 pcs · Thread inlet: M6x1 (standard thread) · Ø piston pin (B): 14 mm · Hole pattern [mm]: 55 x 55 · Outlet type: slanted · Hole spacing outlet: 50 mm · Thread outlet: M6x1 (standard thread) · Camouflaged: No · Hole spacing inlet: 50 mm

GPO piston 40.96 mm | Sachs 502, 50/2, 50/3, 50/4

Nominal diameter: 41 mm · Manufacturer: GPO · Ø outside piston (A): 40.96 mm · Compression height (C): 28 mm · Curvature (D): 2.5 mm · Total piston height (E): 52 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Ø piston pin (B): 12 mm · Piston ring height: 1.5 mm · Piston weight: 90 g

swiing® revival rubber grommet ignition cable | Sachs 503 2AL/2BL/AAL, 535 (A4521)

Manufacturer: swiing® revival parts · Material: Rubber · Color: black · Ø Cable bushing: 5.2 mm · Ø Bundle: 10.5 mm · Ø mounting hole: 8.5 mm · Ø outside: 10.5 mm · Waistband height: 3 mm · Pony OEM number: A4520 · Pony OEM number: A4521 · Sachs OEM no.: 0960 135 000 · Sachs OEM no.: 0960 136 000

Meteor piston 38 mm #B | Sachs 505

Nominal diameter: 38 mm · Manufacturer: Meteor · Ø outside piston (A): 37.98 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 50.5 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Ø piston pin (B): 12 mm · Tolerance group: B · Piston weight: 79 g

Meteor piston 38 mm #A | Sachs 505

Nominal diameter: 38 mm · Manufacturer: Meteor · Ø outside piston (A): 37.97 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 50.5 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Ø piston pin (B): 12 mm · Tolerance group: A · Piston weight: 79 g

Meteor piston 38 mm #C | Sachs 505

Nominal diameter: 38 mm · Manufacturer: Meteor · Ø outside piston (A): 37.99 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 50.5 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Ø piston pin (B): 12 mm · Tolerance group: C · Piston weight: 79 g

Meteor piston 38 mm #D | Sachs 505

Nominal diameter: 38 mm · Manufacturer: Meteor · Ø outside piston (A): 38 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 50.5 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Ø piston pin (B): 12 mm · Tolerance group: D · Piston weight: 78 g

NSK sleeve freewheel gear 1st gear | Sachs 503 automatic

Ø inside: 19 mm · Stock number: HCB 121616 · Manufacturer: NSK · Material: Plastic · Material: Sheet metal (steel) · Material: Steel · Height: 25.3 mm · Ø outside: 25.5 mm

GPO 41 mm cylinder | Sachs 50/3, 50/4 (square inlet) fan-cooled (DE)

Manufacturer: GPO · Material: Gray cast iron · Surface: raw · Area of application: Tuning · Displacement: 55 ccm · Crankshaft stroke: 42 mm · Nominal diameter: 41 mm · Ø Outlet outside: 40 mm · Outlet type: Union nut · Hole spacing inlet: 31 mm · Cooling type: Fan air cooling · Number of fixing points: 4 pcs

ESJOT sprocket 10 teeth | Sachs

Chain pitch: 1/2" x 3/16" · Chain type: 415H · Manufacturer: ESJOT · Material: Steel · Surface: raw · Recording type: Ø15 x SW12 · Number of teeth: 10 pcs

ESJOT sprocket 17 teeth | Sachs

Chain pitch: 1/2" x 3/16" · Chain type: 415H · Manufacturer: ESJOT · Material: Steel · Surface: raw · Recording type: Ø15 x SW12 · Number of teeth: 17 pcs

ESJOT sprocket 18 teeth | Sachs

Chain pitch: 1/2" x 3/16" · Chain type: 415H · Manufacturer: ESJOT · Material: Steel · Surface: raw · Recording type: Ø15 x SW12 · Number of teeth: 18 pcs

Shaft seal FPM 14.96/31.5/3.5 Pinion shaft | Sachs 50/2, 503 (A1134)

Place of use: Pinion shaft · Temperature resistance (min.): -30 - 200 °C · Width: 3.5 mm · Manufacturer: Sachs · Ø inside: 14.96 mm · Ø outside: 31.4 mm · Material: FPM - Fluororubber · Pony OEM number: A1134 · Sachs OEM no.: 0230 011 200 · Sachs OEM no.: 0230 011 100

Copper ring exhaust gasket | Sachs 504, 505, 535

Place of use: Outlet · Manufacturer: Sachs · Material: Copper · Ø outlet inside: 28.4 mm · Thickness: 3.4 mm · Ø outside: 33.8 mm

swiing® ingenious connecting rod bearing 16/21/9.7 "Racing" silver cage | Sachs

Manufacturer: swiing® ingenious parts · Bearing type: Needle roller and cage assembly · Bearing cage: Silver cage · Width: 9.7 mm · Ø inside: 16 mm · Ø outside: 21 mm · Dimension needle bearing: 16/21 x 9.7

GPO 41 mm cylinder kit (square intake) | Sachs 50/3, 50/4 fan-cooled

Manufacturer: GPO · Surface: sandblasted · Material: Gray cast iron · Camouflaged: No · Area of application: Tuning · Displacement: 55 ccm · Crankshaft stroke: 42 mm · Ø piston pin (B): 12 mm · Nominal diameter: 41 mm · Thread inlet: M5x0.8 (standard thread) · Hole pattern [mm]: 51 x 40 · Number of fixing points: 4 pcs · Outlet type: Union nut · Thread outlet: MF40x1.5 (fine pitch thread) · Hole spacing inlet: 31 mm

Koyo needle bearing 19/25.4/19 Gearbox wheel 2nd gear | Sachs 503 ABL, AB CH

Manufacturer: Koyo · Bearing type: Needle sleeve · Stock number: B-1212 · Width: 19.05 mm · Ø inside: 19.05 mm · Ø outside: 25.4 mm · Dimension needle bearing: 19.05/25.4 x 19.05

GPO piston 40.94 mm | Sachs 502, 50/2, 50/3, 50/4

Manufacturer: GPO · Ø outside piston (A): 40.94 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3.2 mm · Total piston height (E): 49.4 mm · Number of piston rings (F): 2 pcs · Nominal diameter: 41 mm · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.5 mm · Thick piston ring: 1.8 mm · Piston weight: 86 g

swiing® revival shells L17 / BO15 shoulder bearing puller

Manufacturer: swiing® revival parts · Peel-off tray: BO15 · Peel-off tray: L17 · Area of application: (Dis)assembly tool

Starter disk small (B-quality) | Sachs 503 AC, ADV

Area of application: Standard

swiing® ingenious cylinder base gasket 1 mm | Sachs 503

Place of use: Cylinder base · Manufacturer: swiing® ingenious parts · Material: Oiled paper · Ø cylinder: 38 - 40 mm · Thickness: 1 mm

swiing® revival shift sleeve | Sachs 50/2, 503 2AL/2BL (A1906)

Manufacturer: swiing® revival parts · Material: Steel · Surface: Hardened · Ø outside: 42.9 mm · Pony OEM number: A1904 · Sachs OEM no.: 0259 003 002

swiing® revival T-slot nut new version | Sachs 50/2, 503 2AL/2BL (A1910)

Manufacturer: swiing® revival parts · Material: Steel · Surface: Hardened · Width: 4.22 mm · Total length: 8.85 mm · Total height: 7.5 mm · Ø Pin: 3.95 mm · Pony OEM number: A1910 · Sachs OEM no.: 0259 021 000

Parmakit 48 mm cylinder kit tuning | Sachs 50 S, 501, 50/4 EKF

Manufacturer: Parmakit · Material: Aluminum · Surface: sandblasted · Displacement: 75 ccm · Nominal diameter: 38 mm · Ø piston pin (B): 14 mm · Outlet type: slanted · Number of fixing points: 4 pcs · Camouflaged: No · Area of application: Tuning

swiing® revival thrust washer 19/38/2.5 gear wheel 1st gear | Sachs 503 AB, ABL (A1198)

Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Thickness: 2.5 mm · Ø outside: 38 mm · Tolerance: DIN 988 (-0.03 mm) · Ø inside: 19.1 mm · Area of application: Standard · Pony OEM number: A1198 · Sachs OEM no.: 0244 201 100

Disc 7.2/10.5/1 clutch shoes | Sachs 503 AB, ABL (A5656)

Manufacturer: Sachs · Material: Steel · Surface: hardened & ground · Thickness: 1 mm · Ø outside: 10.5 mm · Ø inside: 7.2 mm · Pony OEM number: A5656 · Sachs OEM no.: 2844 032 011

swiing® revival thrust washer 14.3/20/0.5 crankshaft | Sachs 503 ABL (A5649)

Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Thickness: 0.5 mm · Ø outside: 20 mm · Ø inside: 14.3 mm · Pony OEM number: A5649 · Sachs OEM no.: 0644 002 121
