Description

The ultimate solution for anyone who wants to rebuild a Puch E50 engine without compromise: With this complete engine rebuild from new parts, you can be sure of an exclusive service from one of the most renowned moped workshops on the scene. No jumbling together of individual parts, but a cleanly built engine with system, know-how and a real cult factor.

Parts included in the set

[DL] Siggnature Zeineinheit workshop (15 min)

39272

Quantity: 22

[DL] Siggnature small parts, consumables & cleaning

39275

Quantity: 2

[DL] Siggnature chemicals

39274

Siggnature appointment QR code

39290

Manufacturer: Siggnature

For: Puch

AKOA engine housing 4-bearing | Puch E50

33189

Manufacturer: AKOA · Material: Aluminum · Puch OEM number: 349.3.10.332.0

For: Puch

Clutch cover replica | Puch E50

15647

Material: Aluminum · Number of fixing points: 4 pcs · Puch OEM number: 349.5.10.335.1

For: Puch

swiing® revival gasket gearbox cover engine 0.5 mm | Puch E50

23391

Manufacturer: swiing® revival parts · Material: Sealing paper · Color: sand-colored · Number of components: 1 pcs · Thickness: 0.5 mm · Ø inside: 106 mm · Ø outside: 116 mm · Number of fixing points: 4 pcs · Alternative version of the Puch OEM number: 349.1.10.349.1

For: Puch

Clutch basket & spur gear 19:96 teeth | Puch E50

30736

Material: Steel · Recording type: Interlocking · Toothing type: helical toothed · Number of teeth: 19 pcs, 96 pcs · Area of application: Standard

For: Puch

Surflex pressure plate clutch | Puch E50

10420

Manufacturer: Surflex · Material: Steel · Surface: galvanized (blue) · Ø outside: 100 mm, 94.5 mm · Area of application: Original

For: Puch

swiing® revival clutch shaft Ø 14 mm | Puch E50

10605

Manufacturer: swiing® revival parts · Total length: 79.2 mm · Ø outside: 13.95 mm · Area of application: Standard

swiing® revival clutch cable individual parts | Puch E50

25574

Manufacturer: swiing® revival parts

For: Puch

swiing® revival oil filler plug with sealing ring | Puch E50

10168

Material: Steel · Surface: galvanized (blue) · Thread type: M10x1.5 (standard thread) · Drive: Slot · Screw head: Lens head · Ø External head: 14 mm · Total length: 14.6 mm · Thread length: 6 mm · Number of components: 2 pcs · Puch OEM number: 364.1.10.660.1 · Manufacturer: swiing® revival parts

For: Puch

swiing® revival tension spring for clutch pressure plate | Puch E50

11239

Manufacturer: swiing® revival parts · Material: Spring steel · Area of application: Original · Place of use: Clutch · Ø inside: 100 mm · Ø outside: 104 mm · Thickness: 2 mm · Alternative version of the Puch OEM number: 349.1.12.009.1

Universal

NGK LB10E spark plug cap / 10 kΩ suppressed

28539

Manufacturer: NGK · Material: Plastic, Rubber · Color: black · Ø cable: 5 mm, 7 mm · Spark plug socket: SAE · Cable available: No · Suppressed: Yes · Resistance: 10000 Ω · Subcategory: Spark plug connector

For: Puch · Sachs · Zündapp Belmondo

swiing® revival ignition plate 90 mm Bosch / DUCATI

23136

Manufacturer: swiing® revival parts · Material: Aluminum · Tension: 6 V · Number of cables: 3 pcs · Cable length: 450 mm, 550 mm · Ø inside: 18.5 mm · Ø outside: 90 mm · Number of fixing points: 4 pcs · Ø bolt circle: 80 mm · Alternative version of the Pony OEM number: A2656 · Alternative version of the Sachs OEM number: 0286 254 008, 0283 130 004

For: Puch

GPO flywheel 6V / 17W clockwise | Puch E50

10828

Manufacturer: GPO · Material: Steel, Plastic · Tension: 6 V · Performance: 17 W · Direction of rotation: right · Ø cone small inside: 11.5 mm · Ø cone large inside: 15 mm · Cone length: 18.5 mm · Cone ratio: 1:5 · Ø Internal flywheel: 91.1 mm · Ø Flywheel outside: 116.5 mm · Thread type: MF26x1.5 (fine pitch thread) · Thread length: 7 mm · Weight: 900 g · Height: 36.5 mm

For: Puch · Sachs · Tomos · Kreidler

Nut M10x1 SW14 Flywheel

25263

Manufacturer: GPO · Material: Steel · Surface: galvanized (blue) · Area of application: Standard · Nut type: Flange nut · Drive: External hexagon · Thread type: MF10x1 (fine pitch thread) · Ø outside: 18.8 mm · Height: 8.9 mm · Width across flats: 14 mm · Pony OEM number: A4513 · Sachs OEM no.: 0942 072 102

Universal

Woodruff key 3 x 3.7 mm

10201

Material: Steel · Total length: 9.15 mm · Width: 3 mm · Height: 3.7 mm

For: Puch

swiing® revival thrust washer set Ø 15 / 17 mm | Puch E50

29901

Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Area of application: Standard · Ø inside: 15 mm, 17 mm · Ø outside: 22 mm, 24 mm · Thickness: 1.1 mm, 1.3 mm, 1.5 mm, 1.7 mm

For: Puch

swiing® revival stud bolt set M6 x 106 | Puch

10842

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Diameter: 5.9 mm · Thread type: M6x1 (standard thread) · Total length: 106 mm · Thread length: 13 mm, 18.5 mm · Width across flats: 10 mm · Drive: External hexagon · Alternative version of the Puch OEM number: 360.1.10.034.1

For: Puch

Snap ring gear wheel | Puch E50

15332

Manufacturer: Puch · Puch OEM number: 901.4656

For: Puch

GPO ignition cover chrome "Puch" emblem black | Puch

18827

Material: Steel · Surface: chrome-plated · Color: Chrome · Height: 48 mm · Ø outside: 130 mm · Ø inside: 125 mm · Number of fixing points: 2 pcs · Puch OEM number: 349.3.10.034.2 · Manufacturer: GPO

For: Puch

Ignition rubber | Puch E50

10392

Material: Rubber · Ø inside: 2.5 mm · Ø inside 2: 5 mm · Waistband height: 2.5 mm · Total length: 30.3 mm · Width: 15 mm · Height: 11 mm · Total height: 15 mm · Color: black

For: Puch

swiing® revival M8x12 oil drain plug & copper ring | Puch E50, Z50

10169

Manufacturer: swiing® revival parts · Material: Steel, Copper · Surface: galvanized (blue) · Color: silver · Thread type: M8x1.25 (standard thread) · Thread length: 12 mm · Screw head: Hexagon · Drive: External hexagon, Slot · Width across flats Screw: 13 mm · Total length: 18 mm · Puch OEM number: 901.1053

For: Puch

swiing® revival clutch springs original | Puch E50

21756

Manufacturer: swiing® revival parts · Material: Spring steel · Area of application: Tuning · Spring design: Pressure spring · Ø wire: 1.6 mm · Ø outside: 8.3 mm · Total length: 28 mm · Number of components: 3 pcs

Details

Place of use

none

Suitable for the following models

Puch

E50
