Puch engine & gearbox

Spring guide decoupling shaft Z50 engine

Manufacturer: Puch

Spring kickstart sprocket NOS | Puch

Spring design: Leaf spring · Manufacturer: Puch · Puch OEM number: 050.1.1334 · Puch OEM number: 329.1.13.034.1

swiing® revival bearing & shaft seal set | Puch ZA50

Manufacturer: swiing® revival parts · Number of components: 11 pcs · Area of application: Standard

Clutch cable | Puch Maxi

Manufacturer: Made in Germany · Material: Brass · Material: Plastic · Material: Steel · Color: black · Quantity: 1 pcs · Ø Stranded wire: 1.5 mm · Total length: 1450 mm · Outer shell length: 1080 mm · Nipple shape: Pears

GPO gasket set 38 mm cylinder fan-cooled | Puch X30 NG-2AH, Velux

Manufacturer: GPO · Number of components: 4 pcs · Ø cylinder: 38 mm · Hole spacing inlet: 38 mm · Ø outlet inside: 22 mm · Hole spacing outlet: 42 mm · Hole pattern [mm]: 44 x 44 mm · Decompressor: Yes · Area of application: Standard

GPO gasket set cylinder original | Puch Maxi S, N / X30 NS, NL, N-2AH

Manufacturer: GPO · Material: Aluminum · Material: Sealing carton · Material: Sealing paper · Number of components: 4 pcs · Thickness: 0.3 mm · Thickness: 0.4 mm · Thickness: 1.8 mm · Ø cylinder: 38 mm · Hole spacing inlet: 32 - 38 mm · Ø outlet inside: 22 mm · Hole spacing outlet: 42 mm · Hole pattern [mm]: 44 x 44 mm · Decompressor: Yes · Area of application: Standard

Clutch shaft Ø 10 mm (old version) | Puch E50

Material: Steel · Ø outside: 9.98 mm · Total length: 79 mm · Area of application: Original · Puch OEM number: 349.1.12.028.1

Driver plate 22 teeth Occ. | Puch ZA50

Manufacturer: Puch · Material: Steel · Ø inside: 16.8 mm · Area of application: Original

Jasil crankshaft | Puch E50

Manufacturer: Jasil · Material: Steel · Cheek type: standard · Crankshaft stroke: 43 mm · Connecting rod length center-center: 90 mm · Total length of crankpin on clutch side: 74 mm · Total length crankpin ignition side: 67 mm · Ø crank webs: 69.9 mm · Ø piston pin (B): 12 mm · Ø Connecting rod eye: 15 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Thread type: MF10x1 (fine pitch thread) · Thread length: 11 mm · Thread length: 15 mm · Dimension needle bearing: 12 / 15 x 14.6 mm (axe 12) · Wide crank webs: 34.3 mm · Length 1st paragraph: 23.3 mm · Length 2nd paragraph: 25 mm · Ø 1st step (on the coupling side): 17 mm · Ø 2nd shoulder (on the clutch side): 15 mm · Length of shoulder (ignition side): 26.3 mm · Weight: 942 g · Number of gears: 1 pcs · Area of application: Standard

swiing® revival bearing press-on sleeve E20 | Puch ZA50 engine

Ø inside: 20.4 mm · Ø outside: 28 mm · Total length: 128 mm · Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Nominal diameter inside: 20.5 mm

NewFren clutch plates (1A quality) | Puch X30

Manufacturer: NewFren · Number of slats: 2 pcs · Area of application: Standard

swiing® revival switching rail | Puch X30 Z50

Manufacturer: swiing® revival parts · Material: Steel · Surface: gas nitrided · Ø outside: 7.3 mm · Total length: 50 mm · Puch OEM number: 320.1.14.024.1

swiing® revival sheet metal cable guide | Puch X30 Sport

Spring design: Leaf spring · Material thickness: 0.3 mm · Manufacturer: swiing® revival parts · Material: Spring steel · Puch OEM number: 349.1.14.203.1

Shift fork NOS | Puch Z50

Manufacturer: Puch · Material: Steel · Surface: blank / oiled · Total length: 54 mm · Height: 19.6 mm · Width: 51.1 mm · Color: silver · Puch OEM number: 320.1.14.025.1

swiing® revival shift arm Z50 engine | Puch X30 Sport

Manufacturer: swiing® revival parts · Material: Aluminum · Surface: anodized · Puch OEM number: 349.2.14.217.1

swiing® revival shift arm Z50 Motor | Puch X30 Velux

Manufacturer: swiing® revival parts · Material: Aluminum · Surface: anodized · Puch OEM number: 320.5.14.017.1

swiing® revival thrust washer 15/22/1.3 clutch | Puch E50, Z50

Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Ø inside: 15 mm · Ø outside: 22 mm · Thickness: 1.3 mm

swiing® revival spring decoupling shaft (new model) | Puch X30 Velux

Manufacturer: swiing® revival parts · Puch OEM number: 320.2.12.022.1

swiing® revival freewheel inner ring Ø 24 mm gearbox | Puch ZA50

Manufacturer: swiing® revival parts · Material: Steel · Surface: gas nitrided · Ø outside: 24.6 mm · Height: 14.5 mm · Puch OEM number: 321.1.13.651.1

Thrust washer 23/28/5 clutch NOS | Puch ZA50

Manufacturer: Puch · Material: Steel · Surface: hardened & ground · Ø inside: 23 mm · Thickness: 5 mm · Ø outside: 28 mm

swiing® revival compression spring starter clutch | Puch ZA50

Spring design: Pressure spring · Manufacturer: swiing® revival parts · Total length: 30 mm

Cylindrical roller Ø 8 x 8 Gearbox NOS | Puch ZA50

Diameter: 8 mm · Width: 8 mm · Manufacturer: Puch · Material: Steel · Surface: Hardened · Puch OEM number: 900.6129

Gearbox shaft NOS | ZA50

Manufacturer: Puch · Material: Steel · Number of teeth: 31 pcs · Toothing type: helical toothed · Recording type: Interlocking · Puch OEM number: 321.1.13.620.2

Countershaft 17 / 11 teeth NOS | Puch Z50

Manufacturer: Puch · Number of teeth: 11 pcs · Number of teeth: 17 pcs · Toothing type: straight toothed · Ø outside: 12.4 mm · Ø outside: 15 mm · Total length: 99 mm · Puch OEM number: 349.1.13.201.1

swiing® revival locking plate gear nut M10 | Puch X30

Manufacturer: swiing® revival parts · Material: Steel · Thread size: M10 · Number of lobes: 1 pcs · Nominal diameter (thread): 10 mm · Ø inside: 10.45 mm · Puch OEM number: 350.1.12.613.1

M8 locking plate clutch | Puch X30 Velux

Material: Steel · Thread size: M8 · Nominal diameter (thread): 8 mm · Number of lobes: 1 pcs · Ø inside: 8.15 mm · Ø outside: 20.1 mm · Thickness: 1 mm

M10 locking plate gear wheel 3 teeth | Puch X30 Velux

Material: Steel · Thread size: M10 · Nominal diameter (thread): 10 mm · Number of lobes: 3 pcs · Ø inside: 10.3 mm

swiing® revival thrust washer 15/22/1.5 clutch | Puch E50, Z50

Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Ø inside: 15 mm · Ø outside: 22 mm · Thickness: 1.5 mm · Puch OEM number: 901.3924

swiing® revival intermediate slat 3-slat version | Puch Z50

Manufacturer: swiing® revival parts · Material: Steel · Area of application: Standard · Puch OEM number: 329.1.12.112.1

swiing® revival emblem "Puch" ignition cover black

Manufacturer: swiing® revival parts · Material: Rubber · Color: black · Shape: round · Puch OEM number: 349.1.10.036.1

Handle carrier 349.1.13.723.2 NOS | Puch

Manufacturer: Puch · Puch OEM number: 349.1.13.723.2

swiing® revival gear shaft | Puch Z50

Material: Steel · Manufacturer: swiing® revival parts · Surface: hardened & ground · Recording type: Interlocking · Total length: 90.45 mm · Puch OEM number: 350.2.13.020.1

Spring to gear wheel | Puch ZA50

Spring design: Ironing spring · Manufacturer: Puch · Material: Spring steel · Surface: raw

swiing® revival intermediate slat | Puch Z50

Manufacturer: swiing® revival parts · Material: Steel · Ø inside: 46 mm · Ø inside: 51 mm · Ø outside: 70 mm · Thickness: 1.5 mm

Surflex driver plate | Puch ZA50

Ø inside: 16.8 mm · Manufacturer: Surflex · Material: Steel · Ø Outer pulley: 90.9 mm · Surface: blank / oiled · Thickness: 32.8 mm · Area of application: Original

Polini breather connection engine M6x1 | Puch

Manufacturer: Polini · Material: Brass · Thread type: M6x1 (standard thread) · Screw head: Hexagon · Drive: External hexagon

swiing® revival sleeve 25/17/14.6 mm | Puch ZA50

Manufacturer: swiing® revival parts · Material: Steel · Surface: burnished · Nominal diameter inside: 17 mm · Ø inside: 16.9 mm · Ø outside: 24.95 mm · Ø Puncture: 20.9 mm · Total length: 14.6 mm · Puch OEM number: 321.1.13.623.1

Shift sleeve | Puch X30 Z50

Material: Steel · Surface: Hardened · Puch OEM number: 050.1.1410

swiing® revival wedge for kickstart lever | Puch E50, Z50

Material: Steel · Surface: galvanized (blue) · Ø outside: 9 mm · Total length: 48 mm · Puch OEM number: 364.2.13.342.1

swiing® revival thrust washer 12.5/18/3 gearbox | Puch Z50

Ø inside: 12.5 mm · Ø outside: 18 mm · Thickness: 3 mm · Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Puch OEM number: 350.1.13.082.1

66HEROES Centering screw M22x1.5 Inox | Puch Z50

Manufacturer: 66HEROES · Material: Chrome steel (colloquially known as stainless steel) · Surface: polished · Thread type: MF22x1.5 (fine pitch thread) · Drive: External hexagon · Nominal diameter (thread): 22 mm · Width across flats: 27 mm · Puch OEM number: 329.1.12.133.1

66HEROES Centering screw M22x1 Inox | Puch Z50

Manufacturer: 66HEROES · Material: Chrome steel (colloquially known as stainless steel) · Surface: polished · Thread type: MF22x1 (fine pitch thread) · Drive: External hexagon · Nominal diameter (thread): 22 mm · Width across flats: 27 mm · Puch OEM number: 050.1.1233

Clutch basket 18 teeth | Puch Z50

Material: Steel · Toothing type: helical toothed · Number of teeth: 18 pcs · Area of application: Standard

Oil seal NBR 17/28/7 A DUO gearbox shaft | Puch Z50

Temperature resistance (min.): -30 - 100 °C · Shaft seal type: A DUO - With rubberized outer casing / two sealing lips. · Ø inside: 17 mm · Ø outside: 28 mm · Width: 7 mm · Manufacturer: Puch · Material: NBR

swiing® revival nut clutch M16x1.5 | Puch ZA50

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Nut type: Hexagon flat nut · Thread type: MF16x1.5 (fine pitch thread) · Drive: External hexagon · Height: 6.5 mm · Nominal diameter (thread): 16 mm · Width across flats: 24 mm

Oil seal NBR 22/40/7 A DUO crankshaft | Puch E50

Place of use: Crankshaft · Temperature resistance (min.): -30 - 100 °C · Shaft seal type: A DUO - With rubberized outer casing / two sealing lips. · Ø inside: 22 mm · Ø outside: 40 mm · Width: 7 mm · Manufacturer: Puch · Material: NBR

swiing® revival ignition rubber | Puch X30 Velux

Manufacturer: swiing® revival parts · Material: Rubber · Color: black

GPO piston pin extractor Ø 10, 12, 14 mm

Manufacturer: GPO · Material: Steel · Surface: burnished · Number of components: 7 pcs · Total length: 130 mm · Diameter: 10 mm · Diameter: 12 mm · Diameter: 14 mm · Width across flats: 10 mm · Width across flats: 17 mm · Area of application: (Dis)assembly tool

Kickstart drive pinion | Puch E50

Material: Metal · Puch OEM number: 349.1.12.329.1

Puch inlet gasket 1.6 mm thick

Place of use: Admission · Thickness: 1.6 mm · Hole spacing inlet: 32 - 38 mm
